Test MOREDETOUR0564

…

PPC MOREDETOUR0564
"LwSyncdWW Wse DetourWW DetourW DpCtrlIsyncdR Fre"
Cycle=Fre LwSyncdWW Wse DetourWW DetourW DpCtrlIsyncdR
Prefetch=0:x=F,0:y=W,1:y=F,1:x=T
Com=Ws Fr
Orig=LwSyncdWW Wse DetourWW DetourW DpCtrlIsyncdR Fre
{
0:r2=x; 0:r4=y;
1:r2=y; 1:r6=x;
2:r2=y;
3:r2=y;
}
 P0           | P1           | P2           | P3           ;
 li r1,1      | li r1,2      | lwz r1,0(r2) | li r1,5      ;
 stw r1,0(r2) | stw r1,0(r2) | li r3,3      | stw r1,0(r2) ;
 lwsync       | li r3,4      | stw r3,0(r2) |              ;
 li r3,1      | stw r3,0(r2) | sync         |              ;
 stw r3,0(r4) | lwz r4,0(r2) | lwz r4,0(r2) |              ;
 sync         | cmpw r4,r4   |              |              ;
 lwz r5,0(r4) | beq  LC00    |              |              ;
              | LC00:        |              |              ;
              | isync        |              |              ;
              | lwz r5,0(r6) |              |              ;
Observed
    0:r5=5; 1:r4=3; 1:r5=0; 2:r1=0; 2:r4=1;
and 0:r5=5; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=1;
and 0:r5=5; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=1;
and 0:r5=5; 1:r4=3; 1:r5=1; 2:r1=2; 2:r4=1;
and 0:r5=4; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=1;
and 0:r5=5; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=1;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=4; 2:r4=1;
and 0:r5=5; 1:r4=1; 1:r5=1; 2:r1=0; 2:r4=2;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=0; 2:r4=2;
and 0:r5=3; 1:r4=5; 1:r5=1; 2:r1=0; 2:r4=2;
and 0:r5=4; 1:r4=5; 1:r5=1; 2:r1=0; 2:r4=2;
and 0:r5=2; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=2;
and 0:r5=4; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=2;
and 0:r5=1; 1:r4=5; 1:r5=0; 2:r1=1; 2:r4=2;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=2;
and 0:r5=3; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=2;
and 0:r5=4; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=2;
and 0:r5=5; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=2;
and 0:r5=4; 1:r4=5; 1:r5=0; 2:r1=0; 2:r4=3;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=1; 2:r4=3;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=3;
and 0:r5=2; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=3;
and 0:r5=3; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=3;
and 0:r5=4; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=3;
and 0:r5=3; 1:r4=5; 1:r5=0; 2:r1=2; 2:r4=3;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=2; 2:r4=3;
and 0:r5=3; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=3;
and 0:r5=5; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=3;
and 0:r5=2; 1:r4=3; 1:r5=0; 2:r1=4; 2:r4=3;
and 0:r5=3; 1:r4=3; 1:r5=0; 2:r1=4; 2:r4=3;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=4; 2:r4=3;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=4; 2:r4=3;
and 0:r5=3; 1:r4=3; 1:r5=0; 2:r1=5; 2:r4=3;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=5; 2:r4=3;
and 0:r5=4; 1:r4=5; 1:r5=0; 2:r1=0; 2:r4=4;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=0; 2:r4=4;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=1; 2:r4=4;
and 0:r5=1; 1:r4=5; 1:r5=0; 2:r1=2; 2:r4=4;
and 0:r5=5; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=1; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=3; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=4; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=5; 1:r4=5; 1:r5=1; 2:r1=2; 2:r4=4;
and 0:r5=3; 1:r4=3; 1:r5=0; 2:r1=0; 2:r4=5;
and 0:r5=3; 1:r4=5; 1:r5=0; 2:r1=0; 2:r4=5;
and 0:r5=2; 1:r4=3; 1:r5=1; 2:r1=0; 2:r4=5;
and 0:r5=2; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=5;
and 0:r5=1; 1:r4=5; 1:r5=0; 2:r1=1; 2:r4=5;
and 0:r5=2; 1:r4=3; 1:r5=1; 2:r1=1; 2:r4=5;
and 0:r5=3; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=5;
and 0:r5=5; 1:r4=3; 1:r5=0; 2:r1=2; 2:r4=5;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=2; 2:r4=5;
and 0:r5=3; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=5; 1:r4=1; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=1; 1:r4=3; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=2; 1:r4=3; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=3; 1:r4=3; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=4; 1:r4=3; 1:r5=1; 2:r1=2; 2:r4=5;
and 0:r5=5; 1:r4=5; 1:r5=0; 2:r1=4; 2:r4=5;
and 0:r5=2; 1:r4=3; 1:r5=1; 2:r1=4; 2:r4=5;
and 0:r5=2; 1:r4=5; 1:r5=1; 2:r1=4; 2:r4=5;
