PPC MOREDETOUR0857
"LwSyncdWW Rfe DetourRW PodWW DetourWW Wse"
Cycle=Rfe DetourRW PodWW DetourWW Wse LwSyncdWW
Prefetch=0:x=F,0:y=W,1:y=F,1:x=W
Com=Rf Ws
Orig=LwSyncdWW Rfe DetourRW PodWW DetourWW Wse
{
0:r2=x; 0:r4=y;
1:r2=y; 1:r5=x;
2:r2=y;
3:r2=x;
}
P0 | P1 | P2 | P3 ;
li r1,4 | lwz r1,0(r2) | lwz r1,0(r2) | lwz r1,0(r2) ;
stw r1,0(r2) | li r3,3 | li r3,2 | li r3,2 ;
lwsync | stw r3,0(r2) | stw r3,0(r2) | stw r3,0(r2) ;
li r3,1 | li r4,1 | | sync ;
stw r3,0(r4) | stw r4,0(r5) | | lwz r4,0(r2) ;
| li r6,3 | | ;
| stw r6,0(r5) | | ;
Observed
1:r1=1; 2:r1=0; 3:r1=1; 3:r4=4; x=3; y=2;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=4; x=3; y=2;
and 1:r1=1; 2:r1=3; 3:r1=1; 3:r4=4; x=3; y=2;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=1; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=1; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=0; 3:r4=1; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=0; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=1; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=3; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=3; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=3; 3:r4=2; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=0; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=1; 3:r4=3; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=0; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=1; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=3; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=1; 3:r1=3; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=3; 3:r1=3; 3:r4=4; x=4; y=2;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=4; x=3; y=3;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=4; x=3; y=3;
and 1:r1=2; 2:r1=1; 3:r1=1; 3:r4=4; x=3; y=3;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=1; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=1; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=0; 3:r4=1; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=2; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=0; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=2; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=1; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=3; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=3; 3:r4=2; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=3; 3:r4=2; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=3; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=3; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=0; 3:r4=3; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=3; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=3; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=1; 3:r4=3; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=0; 3:r4=4; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=0; 3:r4=4; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=0; 3:r4=4; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=1; 3:r4=4; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=1; 3:r4=4; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=1; 3:r4=4; x=4; y=3;
and 1:r1=1; 2:r1=0; 3:r1=3; 3:r4=4; x=4; y=3;
and 1:r1=1; 2:r1=1; 3:r1=3; 3:r4=4; x=4; y=3;
and 1:r1=2; 2:r1=1; 3:r1=3; 3:r4=4; x=4; y=3;
