Test MOREDETOUR0547

…

PPC MOREDETOUR0547
"LwSyncdWW Rfe DetourRW DetourW DpCtrldR Fre"
Cycle=Rfe DetourRW DetourW DpCtrldR Fre LwSyncdWW
Prefetch=0:x=F,0:y=W,1:y=F,1:x=T
Com=Rf Fr
Orig=LwSyncdWW Rfe DetourRW DetourW DpCtrldR Fre
{
0:r2=x; 0:r4=y;
1:r2=y; 1:r6=x;
2:r2=y;
3:r2=y;
}
 P0           | P1           | P2           | P3           ;
 li r1,1      | lwz r1,0(r2) | lwz r1,0(r2) | li r1,4      ;
 stw r1,0(r2) | li r3,3      | li r3,2      | stw r1,0(r2) ;
 lwsync       | stw r3,0(r2) | stw r3,0(r2) |              ;
 li r3,1      | lwz r4,0(r2) | sync         |              ;
 stw r3,0(r4) | cmpw r4,r4   | lwz r4,0(r2) |              ;
              | beq  LC00    |              |              ;
              | LC00:        |              |              ;
              | lwz r5,0(r6) |              |              ;
Observed
    1:r1=2; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=1;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=1;
and 1:r1=4; 1:r4=2; 1:r5=0; 2:r1=0; 2:r4=1;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=0; 2:r4=1;
and 1:r1=4; 1:r4=2; 1:r5=1; 2:r1=0; 2:r4=1;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=3; 2:r4=1;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=1;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=1;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=2;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=2;
and 1:r1=1; 1:r4=2; 1:r5=0; 2:r1=0; 2:r4=2;
and 1:r1=4; 1:r4=2; 1:r5=0; 2:r1=0; 2:r4=2;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=0; 2:r4=2;
and 1:r1=1; 1:r4=2; 1:r5=0; 2:r1=1; 2:r4=2;
and 1:r1=4; 1:r4=2; 1:r5=0; 2:r1=1; 2:r4=2;
and 1:r1=2; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=2;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=3; 2:r4=2;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=3; 2:r4=2;
and 1:r1=1; 1:r4=2; 1:r5=0; 2:r1=3; 2:r4=2;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=3; 2:r4=2;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=2;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=2;
and 1:r1=1; 1:r4=2; 1:r5=0; 2:r1=4; 2:r4=2;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=4; 2:r4=2;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=3;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=3;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=3;
and 1:r1=0; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=3;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=3;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=3;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=4; 2:r4=3;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=4;
and 1:r1=2; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=4;
and 1:r1=4; 1:r4=1; 1:r5=0; 2:r1=0; 2:r4=4;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=0; 2:r4=4;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=1; 2:r4=4;
and 1:r1=0; 1:r4=2; 1:r5=0; 2:r1=1; 2:r4=4;
and 1:r1=2; 1:r4=4; 1:r5=0; 2:r1=1; 2:r4=4;
and 1:r1=0; 1:r4=1; 1:r5=0; 2:r1=3; 2:r4=4;
and 1:r1=1; 1:r4=2; 1:r5=0; 2:r1=3; 2:r4=4;
and 1:r1=1; 1:r4=4; 1:r5=0; 2:r1=3; 2:r4=4;
